Scapular body fractures—should we be fixing more of these?

Introduction

The question of whether we should be fixing more scapular body fractures originates from the historical preference for nonoperative management of these fractures. Recently, there has been a renewed interest in operative management due to the recognition that scapular malunion can cause significant disability. While the treatment pendulum has shifted away from benign neglect, surgical indications remain controversial.

The concept of surgical fixation for scapula fractures is not novel. The first publication of internal fixation for a scapula fracture was in 1913 by Albin Lambotte from a case performed in 1910 (1). Despite numerous surgical case series from surgeons such as Judet (1), it was the nonoperative opinion of Rowe (2) and Schnepp (3) that dictated how these fractures would be treated for ensuing decades. Nonoperative treatment gained traction due to a few inherent properties of the scapula. First, the robust muscular envelope and bloody supply of the scapula ensure that the majority of these fractures will proceed to union. Additionally, the glenohumeral and scapulothoracic joints maintain a large capacity for compensatory motion if the scapula heals in a malunited position. For these reasons, coupled with the fact that the scapula has complex bony anatomy with little area for screw purchase, nonoperative management was the prevailing treatment until the turn of the twenty first century.

The treatment strategy for these fractures changed as the understanding of the fracture patterns, surgical approaches, fixation technology improved and the consequences of scapular malunion were realized. Initial efforts for operative treatment of scapula fractures largely revolved around intra-articular glenoid fractures due to well accepted principles of restoring articular congruity and preventing post-traumatic osteoarthritis (4). More recently, it has been recognized that certain patients with extra-articular scapula fractures can have poor functional outcomes related to altered rotator cuff biomechanics, scapulothoracic dyskinesia, and impingement syndrome (5).

Even though surgical intervention has become increasingly recognized as appropriate treatment for certain patients, identifying these patients still remains elusive. The recent standardization of radiographic parameters for displacement of scapular body fractures has led to improved guidelines for surgical intervention (6). However, even to this date, high quality evidence comparing nonoperative to operative treatment of scapular body fractures does not exist.

Patient evaluation

Scapula fractures are rare injuries, comprising only about 0.5% of all fractures. However, fractures of the scapular body or glenoid neck account for approximately 66–98% of scapula fractures making them the most common fracture pattern (7).

Scapula fractures are usually the result of high-energy mechanisms and patients frequently have associated injuries. These injuries include thorax, ipsilateral upper extremity, head, and spine injuries in 80%, 50%, 48%, and 26%, respectively (8). Scapula fractures should alert the treating orthopaedic surgeon to the potential presence of these other injuries so they can be treated appropriately. Displaced rib fractures can have a significant effect on the outcome of patients with scapular body fractures due to prominence and irritation to the patient (9). Alternatively, scapular fracture diagnosis can be missed or delayed due to the presence of these more significant injuries. Any patient with multiple rib fractures or hemopneumothorax on a chest radiograph should draw the attention to the scapula to ensure it was not injured.

Physical examination of the patient should include gross inspection of the shoulder for significant deformity. This deformity is often characterized by marked shoulder drooping or ptosis on the injured side (Figure 1). The integrity of the skin and assessment for abrasions over the shoulder should be noted. Palpation of the acromion, clavicle and sternoclavicular/acromioclavicular joints can alert the physician to associated fractures that would constitute a double disruption of the shoulder suspensory complex. Range of motion of the shoulder will undoubtedly be painful, but if near full active forward elevation is present it can let the provider know the fracture is likely nondisplaced and can safely be treated conservatively.

Figure 1 A patient with a right scapular fracture displaying the characteristic ptosis or drooping of the shoulder on clinical exam.

If a scapular fracture is identified on a chest radiograph, a standard shoulder radiographic series including true AP shoulder (Grashey), axillary, and scapular Y views to assess for displacement should be obtained. If marked displacement is identified, a dedicated computed tomography scan with 3D reconstructions can help define the displacement indicative of potential surgical benefit.

Classification/radiological evaluation

Numerous classification systems exist for scapular body fractures, most notably including those of Hardegger (4), Ada and Miller (10), as well as the OTA/AO fracture and dislocation classification (11). Both the Hardegger and Ada and Miller classifications were based on radiographic appearance of fracture lines rather than CT scans. These classification systems broadly group fractures into distinct categories such as scapular spine (IB), scapular neck (IIA, B, C), glenoid (III), and body (IV) fractures for the Ada and Miller classification (10). More recently, with the advent of CT scans, detailed mapping of scapular body fractures was able to be performed. Based on a series of ninety patients with operative scapular body fractures, 3-dimensional mapping of the fractures revealed the vast majority of scapular body fractures followed predictable patterns (7). These patterns included a high rate of those with a fracture of the lateral border just inferior to the glenoid, often with extension to the medial border (7). Early classifications systems laid the groundwork for contemporary surgical indications while three-dimensional mapping helps dictate surgical approaches and fixation strategies.

Current radiographic parameters indicating surgical fixation of scapular body fractures include lateral border offset (LBO), angulation, and glenopolar angle (GPA). LBO refers to the amount of displacement of the glenoid component in relation to the lateral border of the scapula. As described by Anavian et al. (6), this is found by measuring the distance between vertical lines drawn from the superolateral tip of the lateral border fracture inferiorly and its corresponding fracture bed at the base of the scapular neck superiorly, as seen on an AP radiograph or three-dimensional CT scan (Figure 2). Angulation of scapular body fractures is best determined on a scapular Y view by measuring the angle formed between parallel lines drawn down the proximal and distal segment cortices (6) (Figure 3). Finally, the GPA refers to the obliquity of the glenoid in respect to the scapular body (12). It is formed by first drawing a line from the superior point of the glenoid cavity to the inferior aspect compared with a second line drawn from the superior point of the glenoid to the inferior angle of the scapula body (6) (Figure 4).

Figure 2 Measurement of the lateral border offset is performed on a three-dimensional computed tomography (3D CT) oriented in the semicoronal scapula plane. The common displacement pattern is for the inferior scapula fragment to lateralize in relation to the superior fragment. The lateral border offset is measured drawing a line from the lateralmost extent of the inferior fragment and another perpendicular line from the lateralmost aspect of the superior fragment.

Figure 3 Angulation deformity is measured on a three-dimensional computed tomography (3D CT) oriented in the transscapular Y orientation. The angle is formed by the intersection of a line running parallel to the proximal fragment and a line running parallel to the distal fragment. Note that even though the inferior teardrop forms a concave surface over the rib cage, it is the more proximal straight portion of the intramedullary canal that is used for the measurement.

Figure 4 Measurement of the glenopolar angle performed on a three-dimensional computed tomography (3D CT) oriented in the coronal scapula plane. The glenopolar angle measurement is made by drawing a line from the inferior to the superior pole of the glenoid fossa and another line from the superior pole to the apex of the scapula’s body’s inferior angle.

Nonoperative treatment

Scapula fractures have classically been treated without surgery. Research has shown successful outcomes with this strategy (13-19). The usual treatment is a sling for about 3 weeks to allow subsidence of pain and swelling. During this time, close vigilance is important, as some patients with extraarticular variants were found to develop increasing deformity in the first weeks of treatment (20). Because of the unique anatomy of the periscapular region, many factors can lead to increased displacement and deformity, such as gravity, asymmetric muscle contractions, and fracture instability. Deforming forces can result in displacement, leading to pain, weakness and glenohumeral imbalance (12,14,15,21,22). Patients must therefore be monitored radiographically to detect early displacement and deformity. Because the scapula is 30 degrees off the plane of the thorax, fractures can be easily missed even in experienced centers (23,24).

The rehabilitation process is an important component regardless of treatment choice. It is important to keep in mind that patients may develop pseudoparalysis and dyskinesia in the early stages of rehabilitation. Additionally, treating surgeons must be aware that these injuries tend to be the result of high energy trauma, and associated injuries to the limb and chest wall must be addressed and accounted for in the rehabilitation process. Associated injuries are reported in up to 90% of cases and can serve as distracting injuries to prompt diagnosis.

Surgical treatment

The scapula is an integral part of the superior shoulder suspensory mechanism, which attaches the upper extremity to the axial skeleton. Seventeen muscular attachments and insertions provide a robust platform from which glenohumeral motion occurs (25). In the setting of a fracture, these can also be sources of deformity and displacement. The levator scapulae muscle, which inserts on the superomedial border of the scapula can medialize the cranial fragment but most commonly the lateral border is translated laterally by its attached musculature. This can be correlated radiographically as LBO and decreased GPA. Posterior surgical approaches are generally safe in regards to vascularity, since the subscapularis muscle originates from the anterior surface of the scapula and provides the blood supply to fracture fragments. The acromion and clavicle serve as the origin for the deltoid muscle. The lateral border of the scapula is the origin of the teres major and minor muscles, as well as the insertion point for the long head of the triceps and provides the most important bony fixation point for stable internal fixation.

As with all operations in orthopedic surgery, the surgical approach is of utmost importance in order to access the area of interest and apply hardware safely. The classic Judet approach is an extensile approach and exposes the entire posterior scapula by elevating the infraspinatus and teres minor, but this is rarely necessary for acute extraarticular fractures (1). Typically, the Judet curvilinear skin incision is utilized and muscular intervals are exploited for fracture reduction and fixation with less soft tissue disruption (26).

Depending on the fracture pattern, different intermuscular windows can be employed. A more limited technique can be used to access portions of the lateral border, scapular spine, and vertebral border. To do this, the muscle plane entered at the spine of the scapula is between the trapezius, originating at the superior margin, and the deltoid at the inferior margin, which is elevated (27,28). The majority of extraarticular fractures can be accessed with little or no release of the deltoid, but the medial portion of the deltoid origin can be released if needed and later repaired.

The acromion can be accessed with an extension of the posterior Judet incision laterally along the posterior acromion. At the vertebral border of the scapula, the intramuscular plane is between the infraspinatus which is elevated, and the rhomboids, which are left attached. The most important window is between the infraspinatus and teres minor for access to the lateral border of the scapula and the posterior glenoid rim. Once this interval is developed, the lateral border of the scapula can be exposed. This is a critical location for fracture reduction, which is typically anteversion of the glenoid and medialization of the lateral border fragment. Once reduced, typical fixation consists of low-profile, relatively flexible implants (Figure 5), such as 2.7 mm locking compression or reconstruction plates.

Figure 5 AP radiographs of extra-articular scapula body fracture comparing pre-fixation and post-fixation. Ipsilateral minimally displaced clavicle fracture treated nonoperatively. (A) AP radiograph of right sided scapular body fracture showing lateral border offset and decreased glenopolar angle; (B) postoperative radiograph showing reduction and stable fixation of scapular body fracture with flexible 2.7 mm plates and screws with restoration of normal bony anatomy.

Outcomes

The surgical treatment of extraarticular scapular fractures remains controversial due to the acceptable results of nonoperative treatment and the lack of high-quality evidence comparing operative to nonoperative treatment. However, not all extraarticular scapular fractures can uniformly be treated nonoperatively with reproducibly excellent clinical outcomes.

Nonoperative treatment of minimally displaced scapular body fractures can reliably produce acceptable clinical results. Numerous authors (15,16,29,30) have published case series regarding the efficacy of nonoperative treatment of such fractures. In a recent retrospective case series of nonoperatively treated scapular body fractures, Gosens et al. (30) demonstrated functional shoulder scores equal to the general population. Nordqvist (14) in an earlier retrospective case series of scapular body, neck, or spine fractures found those with less than a centimeter of displacement largely had normal function when evaluated 10 to 20 years later. Some patients did experience a 25–50% reduction in range of motion in the affected shoulder (14). A subset of patients with displaced scapular neck fractures had poorer outcomes, an observation that was duplicated by Ada and Miller (10).

Subsequently, numerous reports of scapular neck malunions leading to increased shoulder dysfunction surfaced. Romero et al. (12) published a series focusing on malalignment of the glenoid neck marked by a severely decreased GPA. They found that those with a GPA <20 degrees had significantly increased pain, reduced activities of daily living, and abduction weakness at long-term follow-up (12). Bozkurt (15) and Kim (31) published similar findings that correlated a decreased GPA with worse Constant scores at follow-up. Glenopolar <20 degrees remain the relative surgical indication with the largest body of literature support.

The literature has demonstrated that operatively treated scapular body fractures consistently regain preoperative shoulder function at the expense of associated surgical complications. In one of the earlier operative series, Hardegger (4) reported on 33 surgical patients of which 64% returned to normal function while experiencing two infections and two hematomas requiring evacuation. In the largest recent retrospective surgical series of extraarticular scapula fractures by Schroder (32), the mean DASH score was comparable to standard population norms while strength and range of motion were comparable to the contralateral shoulder. The complication rate or secondary surgery rate in this series was 16% (32). In a retrospective matched cohort of 31 nonoperative and operative scapular fractures performed by Jones (5), the final range of motion of both groups was similar and no difference was found in return to work, pain, or complications. A selection bias did occur as those who received surgery had significantly more displacement than those who were treated nonoperatively (5). There were no complications related to scapular osteosynthesis in his series (5).

Conclusions

The management of extraarticular scapular fractures remains controversial due to the lack of prospective, randomized controlled trials justifying surgical intervention. Plain radiographs with evidence of scapular displacement should warrant a CT scan with 3D reconstruction, paying careful attention to LBO, angulation, and the GPA.

In general, the majority of scapula fractures can successfully be treated nonoperatively with excellent functional results. However, numerous case studies exist demonstrating poor outcomes of scapular body or neck fractures with increased deformity (12,14,15). The literature suggests that a GPA less than 20 degrees can lead to significantly worse shoulder function (12,15,30). Additionally, retrospective studies using LBO greater than >2 cm and angulation >45 degrees as a surgical indication demonstrate functional outcomes with near normal strength and range of motion and low complication rates. While numerous cut-offs for surgical indications have been recommended (5,33,34), all indications are considered relative and treatment should be individualized based on patient characteristics and goals.

Should we be fixing more of these? Perhaps, but more importantly, we should be diagnosing more of these and presenting our patients with all of their treatment options, surgical and non-surgical.
